Our wooden pallets and horizontal platforms are manufactured according to each customer’s requirements and under recognized technical specifications compatible with forklift and pallet jack handling. Madepal wooden pallets ensure the storage and transportation of goods and loads, facilitating the handling and movement of heavy, bulky, and difficult-to-handle objects.
ISPM15
We are certified by ICA to perform heat treatment (HT) on our wooden packaging in compliance with International Standard for Phytosanitary Measures No. 15, ISPM 15, which is required for all exports and imports using wooden packaging. We were one of the first companies in Colombia to receive ISPM 15 certification.
Legal Wood
Our pallets are manufactured with Legal Wood from cultivated forests (plantations). We are certified and recognized by the CVC, the highest environmental authority in southwestern Colombia, for our responsible management of legal wood under the program “Legal Origin and Promotion of Sustainable Forest Management.” Diamond Category.
Our Pallets
Madepal maintains 2 standard wooden pallet sizes in our production line which, depending on the required volume and available plant inventory, may be available for immediate delivery.
It is important to note that we only sell pallets in volume and B2B. We do not sell pallets for decoration, furnishings, and/or furniture manufacturing.
STANDARD SIZE
- C1 Pallet UE4 1.20×1.00m STD (In stock)
MADE TO ORDER: Stringer Type (MIN: 100 units)
- C1In Pallet UE4 1.20×1.00m STD CCB Treated
- C2 Pallet UI2 1.20×1.00m 80Plus
- C3 Pallet UI2 1.15×1.00m 80Plus
- C4 Pallet UI2 1.10×1.00m 80Plus
- C5 Pallet UI2 1.15×1.10m 80Plus
- C5e Pallet UI2 1.15×1.10m Winged 80Plus
- C6 Pallet UI2 1.14 x 1.14m STD-14 4C
- C7 Pallet UI2 1.14 x 1.14m STD-11 4C
- C8 Pallet UI2 1.00×1.00m 80Plus
MADE TO ORDER: Block Type (MIN: 200 units)
- T1 Pallet UE4 1.20×1.00m TACO-9 STD
- T1In Pallet UE4 1.20×1.00m TACO-9 STD CCB Treated
- T2 Pallet UE4 1.20×1.00m TACO-8
- T3 Pallet UE4 1.20×0.80m TACO-8
- T4 Pallet UE4 1.20×1.00m TACO-8ML (Special order)
We can offer other dimensions and specifications according to customer requirements. However, these require prior negotiation, a minimum volume commitment, and available production capacity.
References
Below are examples of pallets with different dimensions and international standards:
- ISO pallets (ISO Standard 6780): American Standard. Dimensions 1200 x 1000 mm (47.24 x 39.37 in)
- EUROPALLET (EUR-pallet | Euro-pallet | EPAL-pallet): European Standard 1200 x 800 mm (47.24 x 31.50 in)
- 1150 x 1100 mm (45.28 x 43.31 in)
- 1200 x 1200 mm (47.24 x 47.24 in)
- 1140 x 1140 mm (44.9 x 44.9 in)
- 1250 x 1500 mm (49.21 x 59.06 in)
- 1250 x 1250 mm (49.21 x 49.21 in)
- 1219 x 1016 mm (48 x 40 in)
- 1067 x 1067 mm (42 x 42 in)
- 1219 x 1219 mm (48 x 48 in)
Pallet Drawings
Stringer-Type Pallets:
- C1 Pallet UE4 1.20×1.00m STD
- C2 Pallet UI2 1.20×1.00m 80Plus
- C3 Pallet UI2 1.15×1.00m 80Plus
- C4 Pallet UI2 1.10×1.00m 80Plus
- C5 Pallet UI2 1.15×1.10m 80Plus
- C5e Pallet UI2 1.15×1.10m Winged 80Plus
- C6 Pallet UI2 1.14 x 1.14m STD-14 4C
- C7 Pallet UI2 1.14 x 1.14m STD-11 4C
- C8 Pallet UI2 1.00×1.00m 80Plus
Pallets
These values reflect our identity and guide each of our actions as we contribute to a more sustainable and equitable world.
Two-Way Entry · Four-Way Entry · Single Base · Double Base · Winged · Flat · Reversible.
- Two-Way and Four-Way Entry Pallets: These classifications refer to the number of sides through which a forklift can insert its forks. Two-way entry pallets allow access from two opposite sides, while four-way entry pallets allow access from all four sides, providing greater handling flexibility.
- Single-Base and Double-Base Pallets: The “base” refers to the lower structure of the pallet. Single-base pallets have a simple lower structure, while double-base pallets have a more robust lower structure, allowing them to support heavier loads and stack more securely.
- Winged Pallets: These pallets have extensions on the upper deck that project beyond the lower supports. These “wings” provide a larger load-supporting surface and can facilitate strapping and stretch wrapping.
- Flat Pallets: These are the most common pallets, with a flat and uniform upper surface. They are versatile and suitable for a wide variety of loads.
- Reversible Pallets: These pallets are designed so that both sides can be used as load-bearing surfaces. This increases durability and service life, since the pallet can be flipped when one side becomes damaged.
It is important to consider the specific requirements of each operation when selecting the most appropriate type of pallet.
